主     板

Form Factor

u-ATX Form

CPU Type

Intel Celeron Processors (Socket 478)
Intel Pentium IV Processors (Socket 478)

System Freq

400/533 MHz

Chipset

Intel 845GV + ICH4

Memory

Two slots for 184-PIN DDR DIMMs up to 2GB

Video

Integrated 2D/3D Graphic Accelerator

Audio

AC 97 Codec Audio Subsystem

Ethernet

Onboard RTL810L 10/100 Mbps LAN

Expansion Slot

PCI Slot x 1 available (Max.)

I/O Connector

Serial Port * 1
Parallel Port * 1
USB Port * 2
PS/2 Mini DIN Keyboard Port & Mouse Port * 1
VGA Port * 1
RJ-45 Ethernet Port * 1
Game/MIDI Port * 1
Audio Line-out, Line-in, and Mic-in Jacks * 1

硬碟装置

2.5" or 3.5" IDE HDD x 1

萤     幕

12.1 TFT LCD

触控萤幕

Resistive, Capacitive, or SAW Type

电源供应器

Internal 200W ATX Power Supply

尺     寸

280 (W) x 220 (Min. H) x 280 (D) mm (With 10.4 LCD Screen but without Bundled Device)

週边装备

Integrated TM-200 Thermal Printer, Integrated ICD-2002F/L VFD 20x2 Pole Display

可选择装备

2nd 10.4", 12.1", or 15" LCD with Touch Screen
MSR Card Reader
Multi I/O Card for 2 Serial Ports
